A+ Workstation AS -531AW-TC
- Form Factor Tower
- Supported CPU AMD Threadripper PRO 7000
- CPU Socket 1
-
Max Supported Memory
512 GB DDR5 ECC Supported
- Drive Bays Default: 6 internal fixed 2.5" SATA Fixed 2.5" Drive Bays
-
Power Supply
2000 W Gold
Key Applications
- 2D / 3D Content Creation
- VR Content Development
- AI Inference / Training
- 3D Rendering
- Product Design and Engineering Simulation
Key Features
- AMD Ryzen™ Threadripper™ PRO 7000WX series and Ryzen™ Threadripper™ 7000 series up to 350W TDP processors
- Supports optional CPU closed-loop liquid cooling kit
- CPU and memory overclocking supported
- 4 DDR5 ECC Registered RDIMM / 3DS RDIMM, DDR5-5200 MHz up to total 512 GB
- 2 PCIe 5.0 ×16 slots and 2 PCIe 5.0 ×8 slots
- 2 PCIe 4.0 ×4 M.2 slots (RAID 0, 1) and 1 MCIO connector (PCIe 4.0 ×8) to support 2 NVMe PCIe drives
- 6 internal fixed 2.5″ SATA drive bays and 2 internal fixed 3.5″ SATA drive bays
- 1 Dedicated LAN for IPMI
- Dual 10Gb LAN with Broadcom BCM57416
- 1000W, 1300W, and 2000W power supply options
Request a quote today
Share your email below to express your interest, and a Nextron representative will reach out shortly with detailed information and a personalized quote for your selected product.
More Specifications
- Configurable Configurable by Request
- Cores up to 96
- TDP 350 W
- M.2 2 NVMe M.2 slot
- PCI-e Default: 1 PCIe 5.0 x8 (in x8) HHHL slot
- Dimensions 17.72" (450 mm) Height
- Dimensions 18.5" (470 mm) Depth
- Dimensions 8.07" (205 mm) Width
- Product Model AS-531AW-TC
- LAN 2 RJ45 10 GbE
- SATA Ports Default: 8 SATA
- USB 4 USB 3.2 Gen2 Type-A ports(Rear)
- Video Output 1 VGA
- DIMM Type RDIMM
- Chipset System on Chip
- On-board NVMe NVMe
- Operating Temperature 10°C ~ 35°C (50°F ~ 95°F)
